Model Name |
AMG-12OPMD01N1 |
Screen Size |
12.1" |
Active Display Area (mm) |
246.0 (H) x 184.5 (V) |
Pixel Pitch (mm) |
0.3075(H) x 0.3075(V) |
Display Mode |
Normally white |
Display Resolution (pixel) |
800x600 |
Contrast Ratio |
500:1 |
Display Color |
262k,144 colors |
Brightness (CD/㎡) |
400 |
Backlight |
LED |
Viewing Angles (CR =10) |
140 (H); 110 (V) |
Response Time(Typ.Tr+Tf) |
35ms |
Signal Connector |
VGA/DVI |
Power Consumption |
DC 12V |
Dimension(VxHxT) |
300x248x34 |
Operating Temperature |
-10~65℃ |
Storage Temperature |
-30~70℃ |
Relative Humidity |
5(%RH)~90(%RH) |
