Model Name |
AMG-17OPHA01T1 |
|
Screen Size |
17” |
|
Active Display Area (mm) |
337.92 (H) x 270.33 (V) |
|
Pixel Pitch (mm) |
0.264 (H) x 0.264 (V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
1280x1024 |
|
Contrast Ratio |
1000:1 |
|
Display Color |
16.7M |
|
Brightness (CD/㎡) |
250 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
170 (H); 160 (V) |
|
Response Time(Typ.Tr+Tf) |
8ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
368.13x306.13x54.26 |
|
Operating Temperature |
0～50℃ |
|
Storage Temperature |
-10～70℃ |
|
Relative Humidity |
5(%RH)～90(%RH) |
|
Touch Screen |
Resistive |
